Applications: Recommended for delivery of water for car washing and similar purpose in automobile, service stations and industries.
Construction Tube: Smooth in bore made from Natural and synthetic rubber.
Reinforcement: High tensile synthetic yarn.
Cover:
- Oil and abrasion resistant rubber cover.
- Plain, Wrap Finish.
Temp: -40° F to + 175° F
| Nominal Bore in mm | Tolerance on Nominal Bore in mm | Minimum Thickness of Tube in mm | Minimum Thickness of Cover in mm | Working Pressure | Bursting | ||
|---|---|---|---|---|---|---|---|
| PSI | Bar | PSI | Bar | ||||
| 10.0 | ±0.75 | 1.50 | 1.50 | 375 | 25.0 | 1100 | 80 |
| 12.5 | ±0.75 | 1.50 | 1.50 | 375 | 25.0 | 1100 | 80 |
